Product Introduction
Overview
DANUBE industrial spice dryer is a heat pump drying room designed for commercial and industrial drying of spices, herbs, and other agricultural products. It provides a controlled drying environment for flexible batch processing and is suitable for different raw materials and production requirements.
The system can be used for chili, ginger, turmeric, garlic, pepper, cumin, coriander, herbs, and other spices. The drying configuration can be customized according to the raw material, batch capacity, target moisture content, and final product requirements.
Key Features
Effective Heat Insulation：Polyurethane insulated panels provide effective heat insulation and help maintain a stable drying environment while reducing heat loss.
Adjustable Drying Temperature：The drying temperature can be adjusted from 20°C to 80°Caccording to the characteristics of different spices, herbs, and other materials. This allows suitable drying conditions for different products.
Strong Air Circulation：Explosion-proof fans provide strong and even airflow for effective hot-air circulation and moisture removal throughout the drying room, helping improve drying consistency.
Precise Drying Control：The touchscreen control system enables easy operation and adjustment of temperature, humidity, and drying time, helping maintain controlled drying conditions for different materials.
Safe and Clean Operation：Electrical isolation technology helps improve operational safety. The air-source heat pump produces no direct pollutant emissions during normal operation, providing a cleaner alternative to traditional fuel-fired heating.
Convenient Batch Drying：Drying carts and trays make material loading and unloading convenient and support flexible batch production. The system is suitable for processors handling different types of spices or requiring flexible production schedules.
Dehumidification and Heat Recovery：The drying system removes moisture from the drying chamber during operation, while heat recovery helps improve energy utilization and maintain suitable drying conditions.
Suitable for Different Spices：The drying room can process chili, ginger, turmeric, garlic, pepper, cumin, coriander, cinnamon, herbs, and other suitable agricultural products. Whole, sliced, chopped, or other prepared forms can be processed according to the product requirements.
Drying Process & Complete Spice Drying Solutions
The heat pump drying room provides controlled batch drying for spices and herbs. Depending on the raw material and final product, the process may include:
Cleaning → Cutting / Slicing → Dewatering → Heat Pump Drying → Cooling → Packaging
Some spices can be dried whole, while others require cutting or slicing before drying. The actual process and equipment configuration depend on the material, production capacity, and final product requirements.
In addition to the heat pump spice dryer, DANUBE can provide complete spice drying production lines, including preparation, drying, cooling, grinding, and packaging equipment as required.
Spice Drying Applications
The heat pump drying room is suitable for a variety of spices and herbs in different forms, including whole, sliced, chopped, or prepared products.
Chili and Pepper：Suitable for whole chili, chili pieces, chili flakes, and peppercorns.
Ginger and Turmeric：Suitable for dried ginger slices, turmeric slices, and other prepared root spices.
Garlic：Suitable for drying garlic slices, pieces, and other prepared garlic products.
Seeds and Spices：Suitable for cumin seeds, coriander seeds, and other seed-based spices.
Cinnamon and Herbs：Suitable for cinnamon pieces, dried leaves, herbs, and other plant-based aromatic products.
Heat Pump Drying Room Structure
Technical Specifications
| Technical Parameters of Drying Machine | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Type | Machine Size (MM) | Capacity (KG) | Power | Qty of Fan | Fan Power | Total Power (kW) | Qty of Cart | Qty of Tray | Cart Size (MM) | Tray Size (MM) | |
| 3PA | 3500×2200×2200 | 200–400 | 2.25 | 6 | 0.25/pc | 3.75 | 6 | 78 | 670×810 | 600×800 | |
| 8PA | 5300×2200×2800 | 450–750 | 6 | 12 | 0.37/pc | 10.44 | 6 | 156 | 1210×870 | 600×800 | |
| 15P | 7500×3000×2800 | 900–1500 | 11.25 | 12 | 0.55/pc | 17.85 | 12 | 312 | 1210×870 | 600×800 | |
| 1P D | 1180×680×1800 | 50–80 | 1 | — | — | 1 | — | 15 | — | 600×800 | |
| 3P D | 2100×930×2100 | 120–300 | 3.5 | — | — | 3.5 | — | 40/60 | — | 600×800 | |
| 8P D | 4000×1960×2050 | 650–1000 | 8 | — | — | 8 | 8 | 232 | 600×800 | 600×800 | |
| The drying machine can be customized according to the user’s requirements and production needs. | |||||||||||
Frequently Asked Questions
Q1：What information is needed to select a spice drying machine?
A：To recommend a suitable configuration, DANUBE typically needs the raw material, processing capacity, initial moisture content, target moisture content, and final product form.
Q2：Can DANUBE provide a complete spice drying production line?
A：Yes. In addition to the heat pump drying room, DANUBE can provide related preparation, drying, cooling, grinding, and packaging equipment according to the customer’s processing requirements.
Q3：Can the drying room be customized for my production facility?
A：Yes. The drying room, heat pump configuration, drying carts, trays, and other components can be configured according to the required capacity, available space, material characteristics, and production requirements.
Q4：Can I buy the heat pump drying room as a standalone machine?
A：Yes. The heat pump drying room can be supplied as an individual drying unit or integrated into a complete spice processing and drying line.
Q5：How do I get a suitable spice dryer quotation?
A：Please provide your raw material, required capacity, final product, and target moisture content. DANUBE can recommend a suitable drying configuration and provide a quotation based on your requirements.
